List code Vaisala Việt Nam
100% Finland Origin Vaisala Vietnam HM42
Handheld Humidity and Temperature Meter with HM42PROBE 100% Finland Origin Vaisala Vietnam HM42PROBE
Handheld Humidity and Temperature Meter with HM42PROBE 100% Finland Origin Vaisala Vietnam HMP110 C15F0CHA0
Humidity and Temperature Probe, ±1.5 %RH
Output Signals: 0 … 5 V
CH1: RH(0…100%)/ CH2: T -40…+80 °C
Sensor Protection: Metal Grid with PTFE Membrane Filter ASM212652SP
No Mounting Accessories
Humidity Sensor: Robust general purpose humidity sensor (180R)
Probe Cable Length: Shielded Cable, 1.20m 4-pin M8 Female Straight MMT162
No User’s Guide/ No Converter 100% Finland Origin Vaisala Vietnam HMT330 7S0A101BCAC100A01CABAA1
Premium Humidity and Temperature Transmitter with metal enclosure with Display Cover
Transmitter Type: HMT337 for high humidity (warmed probe option)
Probe Cable: HMP307 Probe with 2m Cable (+180°C)
No Temperature Probe
Calculations: Code RH+T
Standard power supply, 10…35 VDC 24 VAC
Analog Output 4…20mA
Ch1: RH 0…100%RH
Channel 2 T (Temperature Range)
Temperature Range T -40…+80 °C (-40…+176°F)
Metric Units
No Option for Module Slot 1
Option for Module Slot 2
Cable Gland, Metal, EMC M20x1.5/6mm, 8.0 – 11.0mm, Ms/Ni/TPE/NBR, IP68
No Installation Kit for Transmitter and Probe
Humidity Sensor: HUMICAP180 General purpose
Sensor Protection: SST Sintered Filter
English User´s Guide HMT330
No PC Accessories
ISO9001 Compliant Factory Calibration. No Calibration Contract
No Maintenance Contract 100% Finland Origin Vaisala Vietnam HMPX 7E2B1A0A000
Humidity and Temperature Probe
Probe head: Humidity and Temperature Probe (HMP7)
Cable length: HMP7 with 2m cable
Sensor type: Humicap R2 (VHM180) + Pt100
SST sintered filter
Purge and heating: Start-up purge off, interval purge off, probe heat off
Baud rate: Baud rate 19200
Parity, data bit, stop bit: Communication settings (8, N, 2)
Probe Modbus address: Modbus address (240)
Reserved: Reserved character
No Probe mounting accessory
No Connection cable 100% Finland Origin Vaisala Vietnam Indigo510 A1N1A1AAAN
Indigo510 Transmitter
Transmitter for Indigo Probe with Display
Power Supply and Output: 11…35VDC / 24VAC
No Module
Signal Cable Lead-through: Cable Gland
Probe Cable Lead-through: Cable Gland For Probe
Probe Cable 1m
Mounting Plate
SW Configuration: Standard
Documentation: Multilingual Quick Guide
100% Finland Origin Vaisala Vietnam HMT3305N0B001GCAF100A01CGAAA1
will be obsolete soon 100% Finland Origin Vaisala Vietnam INDIGO510 B1N1AAAAAN
INDIGO510 Transmitter w/o Display
Power supply and Output: 11…35VDC / 24VAC
No Module
Signal Cable Lead-through: Cable Gland, Metal M20x1.5/6mm, 5.0 – 9.0mm
Probe Cable Lead-through: Cable Gland for One Probe
Probe Cable: Probe Cable 0.2m CBL210896-03MSP
Mounting Plate DRW252186SP
SW Configuration: Standard
Documentation: Multilingual Quick Guide
Reserved 1: For Future Purposes 100% Finland Origin Vaisala Vietnam HMPX 5D1B0A0A0F0
Humidity and Temperature Probe
Probe Head: Humidity and Temperature Probe HMP5
Cable Length: HMP5 with 10m cable
Sensor Type: Composite R2 (VHM180C)
Filter Type: SST sintered filter
Purge and Heating: Purge on, probe heat off
Baud rate 19200
Parity, Data Bit, Stop Bit: Communication settings 8, N, 2
Probe Modbus Address: Modbus address 240
Reserved character
Probe Mounting Accessory: Mounting flange
Connection Cable No connection cable
100% Finland Origin Vaisala Vietnam HMW92D
RH + T Wall mount Transmitter, ±1.7 %RH, 4…20 mA, Display 100% Finland Origin Vaisala Vietnam HMD60 A1A1A1B2A0
Humidity and Temperature Duct Transmitter
Probe Length Standard (25 cm)
Output Signal: 4…20 mA (Loop powered)
Ch1: RH (0…100%)
Ch2: T (-20…+80°C)
Identity: Vaisala
Sensor: Humicap R2
Filter: Sintered Stainless Steel Filter HM46670SP
Bushing 1 (small): Conduit Fitting NPT1/2″ 210675SP
Blusing 2 (large): Cable Gland (6…12mm)
None User Guide 100% Finland Origin Vaisala Vietnam HMD62
RH+T Duct Transmitter, ±1.5 %RH, 4…20 mA 100% Finland Origin Vaisala Vietnam HMD62
RH+T Duct Transmitter, ±1.5 %RH, 4…20 mA 100% Finland Origin Vaisala Vietnam HM70 F0B1A0EB
Handheld Humidity and Temperature Meter, ±1 %RH
No Indicator Accessories
Long Probe for -50…+120 °C (-58…+248 °F), HMP76
Calibration Certificate at Room Temperature
No Probe Accessories
No Connection Cable to a Transmitter
Carrying Case: Weatherproof Carrying Case for Long Probe
Manual Language: Multilingual Quick Guide for HM70 Handheld Humidity and Temperature Meter 100% Finland Origin Vaisala Vietnam Code: HMT330 7S0A001BCAE200A0AACBCA1
Humidity and Temperature Transmitter
Hiện dòng HMT330 hết sản xuất, thay thế bằng dòng Indigo + Smart Probe 100% Finland Origin Vaisala Vietnam HMT337SERVICES (HMT330 7S0A001BCAE200A0AACBCA1)
Humidity Calibration, 5 Points (RHCALSTD)
15 | 33 | 54 | 75 | 95
Temperature calibration at room temperature (+/-2°C from 23°C) (ROOMTEMP)
23 100% Finland Origin Vaisala Vietnam HMT337SERVICES (HMT330 7S0A001BCAE200A0AACBCA1)
Humidity Calibration, 5 Points (RHCALSTD)
15 | 33 | 54 | 75 | 95
Temperature calibration at room temperature (+/-2°C from 23°C) (ROOMTEMP)
23
Additional Analog Output Calibration, 3 points (ANALOGCAL1) 100% Finland Origin Vaisala Vietnam HMW92D
RH + T Wall mount Transmitter, ±1.7 %RH, 4…20 mA, Display 100% Finland Origin Vaisala Vietnam 19730HM
MgCl2 Salt (33 %RH) for One Chamber 100% Finland Origin Vaisala Vietnam 19731HM
NaCl Salt (75 %RH) for One Chamber 100% Finland Origin Vaisala Vietnam DM70
Handheld Dewpoint Meter for Spot-Checking Applications
DM70 is obsolete and replaced by Indigo80 and DMP8 100% Finland Origin Vaisala Vietnam Indigo80 B0N0N1N0
Handheld Indicator
Power Supply Unit: Euro AC-adapter, including USB-C cable
No Indicator Accessories
No Connection Cables for Transmitters
100% Finland Origin Vaisala Vietnam DMP80 BG0A0AS0
Handheld Dew Point Probe
Probeset: Probe with Range [-70 … +60°C Td], DRYCAP®180M sensor
Thread: Mechanical connection, ISO G1/2” thread
No Probe connection cables
Filter option for probe head
No Accessories for ISO G1/2” thread
Multilingual Quick Guide
Standard factory calibration 100% Finland Origin Vaisala Vietnam HMT330 830B101BCAL100F0ACNBAA1
will be obsolete soon 100% Finland Origin Vaisala Vietnam Indigo520 A1N9AANAAN
INDIGO520 Transmitter with Display
Power Supply and Output • 15…35VDC / 24VAC
No Module
Cable Gland Set, Plugged + All Lead-Dthroughs
Cable Gland for One Probe
Probe Cable 0.2m CBL210896-03MSP
Mounting: Standard mounting kit
SW Configuration: Standard
Multilingual Quick Guide
Reserved 1: None 100% Finland Origin Vaisala Vietnam HMPX 8M2B1A0A000
Humidity and Temperature Probe
Probe Head: Humidity and Temperature Probe HMP8
Cable Length: HMP8 with 10m cable
Sensor Type: Composite R2 (VHM180C)
Filter Type: SST sintered filter
Purge and Heating: Purge on, probe heat off
Baud rate 19200
Parity, Data Bit, Stop Bit: Communication settings 8, N, 2
Probe Modbus Address: Modbus address 240
Reserved character
Probe Mounting Accessory: Mounting flange
Connection Cable No connection cable
100% Finland Origin Vaisala Vietnam HMT330 360B041BCAD160D0ACABDA1
will be obsolete soon 100% Finland Origin Vaisala Vietnam INDIGO520 B2N9AANAAN
INDIGO520 Transmitter without Display
Power Supply and Output: Universal AC-Power (100…240 VAC), EUR Cord
No Module
Cable Gland Set, Plugged + All Lead-throughs
Cable Gland for One Probe
Probe Cable 0.2m CBL210896-03MSP
Mounting: Standard mounting kit
SW Configuration: Standard
Multilingual Quick Guide
Reserved 1: None 100% Finland Origin Vaisala Vietnam HMPX 3K2B1A0A000
Humidity and Temperature Probe
Probe Head: HMP3 general purpose probe
Cable Length: HMP3 with 10m cable
Sensor Type: Humicap R2 sensor, no sensor purge
Filter Type: Sintered Stainless Steel filter HM47280SP
Purge and Heating: Start-up purge off, interval purge off, probe heat off
PBaud Rate: 19200 – Use with Indigo transmitters
Parity, Data Bit, Stop Bit 8, N, 2 – Use with Indigo transmitters
Parity, Data Bit, Stop Bit 8, N, 2 – Use with Indigo transmitters
Probe Modbus Address 240 – Use with Indigo transmitters
Probe Mounting Accessory No accessories
Connection Cable No connection cable 100% Finland Origin Vaisala Vietnam HMT370EX 74R1NB1AD1NN
Intrinsically Safe Humidity and Temperature Transmitter HMT370EX
HMP377 Probe for High Humidities
Ex Certificate and Region: CML Certificate for HMT370EX (Japan)
HMP377: Probe Cable 5 m, max +180 °C
Sensor Protection: Plastic grid & SST net filter, All probes DRW010281SP
No Probe Accessories
Transmitter with Display and Keypad, must be protected against direct sunlight to maintain EX-protection!
Output Units: Metric Units
Ch1: RH (0…100%)/ Ch1: T (-20…+80 °C)
Cable Lead-through: Cable Gland M20x1.5 for Cable 5…11 mm 265207SP
No Transmitter Accessories 100% Finland Origin Vaisala Vietnam HMP370EX 74R1NN
Intrinsically Safe Humidity and Temperature Probe
Probe model: HMP377 Probe for High Humidities
Ex certification and Region: CML Certificate for HMP370EX
Probe Cable Length and Sensor: HMP377: Probe Cable 5 m, max +180 °C
Sensor Protection: Plastic grid & SST net filter, All probes DRW010281SP
No Probe Accessories 100% Finland Origin Vaisala Vietnam HMP155 A2JB11A0A3A1A0A
Humidity and Temperature Probe for Outdoor Applications
Probe Type: HMP155A: Analog Output for Humidity and Temperature
Analog Output (CH1+CH2) Output 0…1V
Ch1: Air Temperature in range -80 … +60°C (-112…+140°F)
Ch2: RH (0…100%RH)
Metric Units
General Purpose HumiCap 180R
No No Heating/ No chemical Purge
Sintered PTFE-filter, Best protection for Long-term Stability
30m Cable with Connector on HMP155 End + Open Leads on the Other End
No External Temperature Probe
RH&T-calibration in room temperature
Standard Installation Kit 100% Finland Origin Vaisala Vietnam HMP155 A2JB11A0A3A1B0A
Humidity and Temperature Probe for Outdoor Applications
Probe Type: HMP155A: Analog Output for Humidity and Temperature
Analog Output (CH1+CH2) Output 0…1V
Ch1: Air Temperature in range -80 … +60°C (-112…+140°F)
Ch2: RH (0…100%RH)
Metric Units
General Purpose HumiCap 180R
No No Heating/ No chemical Purge
Sintered PTFE-filter, Best protection for Long-term Stability
30m Cable with Connector on HMP155 End + Open Leads on the Other End
No External Temperature Probe
RH&T-calibration in room temperature
Maintance Calbe: USB-M12 Service Cable
Standard Installation Kit 100% Finland Origin Vaisala Vietnam HMP60 C12A1A1A0
Humidity and Temperature Probe, ±3 %RH
Output Signal: 0 … 5 V
Ch1: RH (0…100%)/ Ch2: T -40…+60 °C
Sensor Protection: Plastic Grid with Filter DRW010525SP
Mouting Accessories: Pair of plastic nuts 18350SP
Humidity Sensor: Intercap sensor
No Probe Cable Length
No User’s Guide/ No Converter 100% Finland Origin Vaisala Vietnam GMP251 A4B0C1N1
CO2 Probe for % Measurements
Probe Type: 0…20% Probe with Standard Filter
Output Mode: 0…5V Output
Temperature Setpoint +37°C (+99°F)
Pressure Compensation: Pressure Setpoint 1013 hPa
Background Gas Compensations: Background Gas Setpoint 19.7%O2, 93%RH
Cable:1.5 m Probe Cable with Open Wires 223263SP
No Mounting Accessories
Single Package 100% Finland Origin Vaisala Vietnam INDIGO202 1A4A0
INDIGO202 Digital Transmitter
Display With Metric Units
Analog Outputs Type Modbus RTU Over RS-485 Serial Protocol
Cables: Remote Probe Cable, 10m INDIGOCABLE10M
No External Power
No Customization
100% Finland Origin Vaisala Vietnam GMP251 A1A0A4N1
CO2 Probe for % Measurements
Probe Type: 0…20% Probe with Standard Filter
Output Mode: Digital Output RS-485
Temp Compensation: Temp Setpoint +25°C (+77°F)
Pressure Compensation: Pressure Setpoint 1013 hPa
Background Gas Setpoint 0%O2, 0%RH
10 m Probe Cable with Open Wires 216546SP
No Mounting Accessories
Single Package 100% Finland Origin Vaisala Vietnam DMT143 L1C1Z1A5A0ASX
Miniature Dew Point Transmitter
Mechanical Connection: ISO G1/2″ Long Probe with DRYCAP180M Sensor
Digital Interface: Digital Output RS-485
Analog Signal Output: 4…20 mA, 3.6 mA error state
Analog Output Scaling: -80…+20 °C Td
Alarm LED Setpoint: Deactivated, LED always off
Process gas air
Pressure Setting for Optimized Accuracy: 1 bar Absolute
Cable 10.0 m (32.8 ft) with Open Leads HMP50Z1000SP
Standard sintered filter DRW010335SP
No Accessories ONLY for ISO1/2″ Thread
Standard package for DMT143
Vaisala identity
User Guide Language: Multilingual guide 100% Finland Origin Vaisala Vietnam TMW90 21A1A00A0
Room Temperature Transmitter
2-wire current output
Output Signal: 4…20 mA 2-wire (loop-powered)
Output scaling for temperature T -5 … +55 °C (+23 …+131°F)
Display and colour
Display Cover White RAL9003 (visible display) DRW237339SP
Metric units
None Relay operation
Relay set-point and hysteresis None
Identity With adjustment trimmers
Quick reference guide No User’s Guide
100% Finland Origin Vaisala Vietnam HMD62
RH+T Duct Transmitter, ±1.5 %RH, 4…20 mA 100% Finland Origin Vaisala Vietnam TMD62
Temperature Duct Transmitter, ±0.1 °C, 4…20 mA 100% Finland Origin Vaisala Vietnam DPT146 A1DCX110A0A
Dewpoint and Pressure Transmitter, 1…12 bar, Td -70…30 °C
Mechanical Connection: Mechanical Connection: ISO G1/2″ Process Connection Thread
Measurement Parameters: Dewpoint, Pressure, ppm, Dewpoint at atm
Analog Output Ch1 & Ch2 + RS-485 as Standard: 4…20 mA
Ch1: Dew Point -60…+40 °C (-76 …+104 °F) Td/f
Ch2: Absolute Pressure, free scale
Metric Units
Cable for Analog Outputs and Power Supply (Port I): 0.3 m (1.0 ft) M8 Shielded Cable with Open Wires
Cable for RS485 Line and Power Supply (Port II): No Service Cable
No Installation Accessories ONLY for ISO1/2″ Thread
No Special Features
No User’s Guide 100% Finland Origin Vaisala Vietnam DMT152 A1DBB10A100A1X
DMT152 Transmitter for Low Dewpoint with a measurement range of -80 to -20°C
Mechanical Connection: ISO 1/2″ Thread
Measurement Parameters: Td/f, ppm
Analog Output Ch1 & Ch2 + RS-485 as Standard: 4…20 mA
Ch1: -80…+20 °C Td/f
Ch2: -80…+20 °C Td/f
Metric Units/ Pressure Not Specified No ppm Output
Sensor Protection: Mesh Filter 18um Stainless Steel
Cable for Analog Outputs and Power Supply (Port I): Shielded Cable, 2m, snap in connector
No Service Cable
Package: Cardboard Box
Quick Reference Guide DMT152 100% Finland Origin Vaisala Vietnam HMT 120 HB0AXA12A2C0Z
Humidity and Temperature Transmitter, ±1.5 %RH, 4…20 mA without display
Output Parameters: Humidity output only, HMP110 Stainless Steel Probe
Transmitter Type: 3 m Cable for Remote Probe HMT120Z300
Output 4…20mA, 2-wire loop-powered
Channel 1: custom Scaling (BUỘC CONFIRM KHI ORDER)
Channel 2 No Output
Metric Units
Sensor Protection: Plastic Grid with PTFE filter for Steel Probe DRW010525SP
No Transmitter installation
Installation Kit for Probe: Duct Installation Kit 215619
Cable Blushings: Conduit Fitting NPT 1/2″
No PC Accessories
Multilingual Manual 100% Finland Origin Vaisala Vietnam Indigo520 B2N1A1AAAN
INDIGO520 Transmitter without Display
Universal AC-Power (100…240 VAC), EUR Cord
No Module
Cable Gland, Metal M20x1.5/6mm, 5.0 – 9.0mm
Cable Gland for One Probe
Probe Cable 1m CBL210896-1MSP
Retrofit Mounting Plate for HMT330, DMT340, PTU300, MMT330 DRW252186SP
Standard SW Configuration 100% Finland Origin Vaisala Vietnam HMPX 7E2B1A0A0G0
Humidity and Temperature Probe
Humidity and Temperature Probe HMP7
HMP7 with 2m cable
Humicap R2 (VHM180) + Pt100
SST sintered filter
Purge off, probe heat off
Baud rate 19200
Communication settings 8, N, 2
Modbus address 240
Reserved character
Swagelok NPT 1/2″
No connection cable 100% Finland Origin Vaisala Vietnam 19729HM
LiCl Salt (11 %RH) for One Chamber 100% Finland Origin Vaisala Vietnam 19731HM
NaCl Salt (75 %RH) for One Chamber 100% Finland Origin Vaisala Vietnam 15778HM
Vaisala INTERCAP® Humidity Sensor (1 pc) 100% Finland Origin Vaisala Vietnam DMT143 L1C1Z1A510ASX
Miniature Dew Point Transmitter
Mechanical Connection: ISO G1/2″ Long Probe with DRYCAP180M Sensor
Digital Interface: Digital Output RS-485
Analog Signal Output: 4…20 mA, 3.6 mA error state
Analog Output Scaling: -80…+20 °C Td
Alarm LED Setpoint: Deactivated, LED always off
Process gas air
Pressure Setting for Optimized Accuracy: 1 bar Absolute
Cable 10.0 m (32.8 ft) with Open Leads HMP50Z1000SP
Standard sintered filter DRW010335SP
Sensor Protection: Sintered Stainless Steel Filter for Long Probe HM47280SP
Standard package for DMT143
Vaisala identity
User Guide Language: Multilingual guide 100% Finland Origin Vaisala Vietnam DMT143 L3C1A1A3AAASX
Miniature Dew Point Transmitter
Mechanical Connection: ISO G1/2″ Long Probe with DRYCAP180M Sensor
Digital Interface: RS-485 MODBUS RTU output 19200 N 8 1
Analog Signal Output: 4…20 mA, 3.6 mA error state
Analog Output Scaling: -80…+20 °C Td
Alarm LED Setpoint: Off, only fault indication
Process gas air
Pressure Setting for Optimized Accuracy 1 bar Absolute
Cable 3.0 m (9.8 ft) with Open Leads HMP50Z300SP
Sensor Protection Standard sintered filter DRW010335SP
Cable Adapter DMT242 to DMT143
Standard package for DMT143
Vaisala identity
Multilingual guide 100% Finland Origin Vaisala Vietnam HMM170 6GEC1A2A
Humidity Module
Output Signal: 0… 5 V (5.5 V when in error state)
Ch1: T -70… +180 °C
Ch2: Relative Humidity (RH) 0… 100 % RH
Ch3: Td/f with Warmed Probe -20…+100 °C (-4…+212 °F)
Probe type and cable length Stainless Steel Probe with 2 m / 6.5 ft cable (-70 °C… +180 °C)
Humidity sensor type and chemical purge Standard sensor, startup purge on, 24 h interval purge on
Sensor protection: Sintered Filter AISI 316L HM47280SP
100% Finland Origin Vaisala Vietnam DMT143 G1G1A1A3A0ASX
Miniature Dew Point Transmitter
Mechanical Connection: ISO G1/2″ Probe with DRYCAP®180D Sensor
Digital Interface: Digital Output RS-485
Analog Signal Output: 4…20 mA, 0 mA error state
Analog Output Scaling: -80…+20 °C Td
Alarm LED Setpoint: Off, only fault indication
Process gas air
Pressure Setting for Optimized Accuracy: 1 bar Absolute
Cable 3.0 m (9.8 ft) with Open Leads HMP50Z300SP
Standard sintered filter DRW010335SP
No Accessories ONLY for ISO1/2″ Thread
Standard package for DMT143
Vaisala identity
User Guide Language: Multilingual guide 100% Finland Origin Vaisala Vietnam HMT310 3C5A1BCK14BBDA1A2
Premium Humidity and Temperature Transmitter with metal enclosure
HMT313 for duct mounting or outdoor mounting
Transmitter Type: Warmed probe, parameters Td+Tdf+x available
Standard Mounting Plate
Standard power supply, 10…35 VDC 24 VAC
Analoge Output Signal: 4…20mA
Ch1: RH 0…100%RH/ Ch2: below Temp range
T 0…+100 °C (+32…+ 212 °F)
Output Unit: Metric
Cable Connector: 8-Pole Connector with 5m Cable 212142
User´s Guide English
HMT313 with 2 m Cable, 80 mm probe, max +80 °C
HUMICAP180RC Composite Sensor with Chemical Purge Default
HMT313/317: Plastic Grid & Stainless Steel Netting DRW010281SP
No Temperature Probe/ No Installation Kit
Calibration Certificate At Room Temperature 100% Finland Origin Vaisala Vietnam HMM100 45A2D0
Humidity Module for Environmental Chambers
Output Signal: 0…5 V
Probe type: Stainless cable 3 m
Measured Parameter: RH
Humidity Sensor type: Humicap 180 for fast response
sensor Protection: Sintered Stainless Steel Filter HM47280SP
No User’s Guide 100% Finland Origin Vaisala Vietnam HMD62
RH+T Duct Transmitter, ±1.5 %RH, 4…20 mA 100% Finland Origin Vaisala Vietnam TMD62
Temperature Duct Transmitter, ±0.1 °C, 4…20 mA 100% Finland Origin Vaisala Vietnam TMW90 21A1A00A0
Room Temperature Transmitter
2-wire current output
Output Signal: 4…20 mA 2-wire (loop-powered)
Output scaling for temperature T -5 … +55 °C (+23 …+131°F)
Display and colour
Display Cover White RAL9003 (visible display) DRW237339SP
Metric units
None Relay operation
Relay set-point and hysteresis None
Identity With adjustment trimmers
Quick reference guide No User’s Guide
100% Finland Origin Vaisala Vietnam HMD62
RH+T Duct Transmitter, ±1.5 %RH, 4…20 mA 100% Finland Origin Vaisala Vietnam TMD62
Temperature Duct Transmitter, ±0.1 °C, 4…20 mA 100% Finland Origin Vaisala Vietnam HMP60 A12A0A1A0
Humidity and Temperature Probe, ±3 %RH
Output Signals 0 … 1 V
Channel 1: RH (0…100%)
Channel 2: T -40…+60 °C
Sensor Protection Plastic Grid with Filter DRW010525SP
No Accessories
Humidity Sensor Intercap sensor
No Probe Cable Length 100% Finland Origin Vaisala Vietnam DTR504
Radiation Shield DTR504 Assembly 100% Finland Origin Vaisala Vietnam HMT330 360B041BCAD160D0ACABDA1
Premium Humidity and Temperature Transmitter with metal enclosure
This model will be obsolete soon 100% Finland Origin Vaisala Vietnam INDIGO520 A1N1B6AAN
INDIGO520 Transmitter with Display
Power Supply and Output: Power Supply and Output: 15…35VDC / 24VAC
Metal Cable Gland for 5-9 mm Cable
Cable Gland for Two Probes
Probe Cable 3m, 2pcs
Retrofit Mounting Plate for HMT330, DMT340, PTU300, MMT330
SW Configuration: Standard
Multilingual Quick Guide 100% Finland Origin Vaisala Vietnam HMPX 7E1A2A5A0A000
HMP7 probe for high humidity
Probe Head: HMP3 general purpose probe
Cable Length: HMP7 with 2m cable
Sensor Type: Humicap R2 composite sensor, allows sensor purge
Filter Type: Plastic grid & SST net filter DRW010281SP
Purge and Heating: Start-up purge on interval purge off, probe heat off
PBaud Rate: 19200 – Use with Indigo transmitters
Parity, Data Bit, Stop Bit 8, N, 2
Probe Modbus Address 240
Probe Mounting Accessory No accessories
Connection Cable No connection cable 100% Finland Origin Vaisala Vietnam TMPX 1A1A0A0A000
Temperature Probe
Temperature Probe TMP1 with 2m cable
Temperature Sensor PT100
No Filter/ Reserved character
English calibration certificate 100% Finland Origin Vaisala Vietnam INDIGO520 A1N1BBAAN
INDIGO520 Transmitter with Display
Power Supply and Output: Power Supply and Output: 15…35VDC / 24VAC
Metal Cable Gland for 5-9 mm Cable
Cable Gland for Two Probes
Probe Cable 0.2m, 2pcs
Retrofit Mounting Plate for HMT330, DMT340, PTU300, MMT330
SW Configuration: Standard
Multilingual Quick Guide 100% Finland Origin Vaisala Vietnam HMPX 7F1A2A5A0A000
HMP7 probe for high humidity
Probe Head: HMP3 general purpose probe
Cable Length: HMP7 with 2m cable
Sensor Type: Humicap R2 composite sensor, allows sensor purge
Filter Type: Plastic grid & SST net filter DRW010281SP
Purge and Heating: Start-up purge on interval purge off, probe heat off
PBaud Rate: 19200 – Use with Indigo transmitters
Parity, Data Bit, Stop Bit 8, N, 2
Probe Modbus Address 240
Probe Mounting Accessory No accessories
Connection Cable No connection cable 100% Finland Origin Vaisala Vietnam TMPX 1B1A0A0A000
Temperature Probe
Temperature Probe TMP1 with 2m cable
Temperature Sensor PT100
No Filter/ Reserved character
English calibration certificate 100% Finland Origin Vaisala Vietnam HMT330WPA
Installation kit for mounting the warmed probes of the Indigo-compatible HMP7 and TMP1 probes 100% Finland Origin Vaisala Vietnam ASM213382SP
Magnetic probe holder for Ø 12 mm probe heads 3 100% Finland Origin Vaisala Vietnam PTB110 3R0DB
PTB110 Wall Mount Barometer, 0…2.5, 0…5 V, or 500…1100 Hz Output
Pressure Range 800-1100 hPa
Internal Model: Digital Output RS-485
Standard Installation Kit 100% Finland Origin Vaisala Vietnam HMT370EX 11A2NA1AA1NN
Intrinsically Safe Humidity and Temperature Transmitter HMT370EX
HMP371 Probe for Wall Mounting
Fixed Probe, max +60°C with HUMICAP® R2
Stainless Steel Sintered Filter (AISI 316L) for General Use
Stainless Steel Sintered Filter (AISI 316L) for General Use
Probe Accessories: No Accessories
Transmitter without Display and Keypad
Metric Units
Ch1: 0…100 %/ Ch2: 0…100 %
Cable Gland M20x1.5 for Cable 5…11 mm
No Transmitter Accessories 100% Finland Origin Vaisala Vietnam HMW92
RH + T Wall mount Transmitter, ±1.7 %RH, 4…20 mA 100% Finland Origin Vaisala Vietnam DMT152 C1DBY11A400A1X
DMT152 Transmitter for Low Dewpoint with a measurement range of -80 to -20°C
Mechanical Connection: UNF 3/4 -16 Thread
Measurement Parameters: Td/f, ppm
Analog Output Ch1 & Ch2 + RS-485 as Standard: 4…20 mA
Analog Output Parameter or Function for Ch1: -80…+20 °C Td/f
Analog Output Parameter or Function for Ch2: free scaling ppm (confirm when order)
Metric Units
Ambient Pressure 1 bar(a) 14.76 psi(a)
Mesh Filter 18um Stainless Steel
Cable for Analog Outputs and Power Supply (Port I): Shielded Cable, 5.0m, 4-pin M8 Female Straight
Carton Package 100% Finland Origin Vaisala Vietnam DMT152 C1DBY11A400A1X
DMT152 Transmitter for Low Dewpoint with a measurement range of -80 to -20°C
Mechanical Connection: UNF 3/4 -16 Thread
Measurement Parameters: Td/f, ppm
Analog Output Ch1 & Ch2 + RS-485 as Standard: 4…20 mA
Analog Output Parameter or Function for Ch1: -80…+20 °C Td/f
Analog Output Parameter or Function for Ch2: free scaling ppm (confirm when order)
Metric Units
Ambient Pressure 1 bar(a) 14.76 psi(a)
Mesh Filter 18um Stainless Steel
Cable for Analog Outputs and Power Supply (Port I): Shielded Cable, 5.0m, 4-pin M8 Female Straight
Carton Package 100% Finland Origin Vaisala Vietnam HMP370EX 82T2DA1AE1NN
Intrinsically Safe Humidity and Temperature Transmitter HMT370EX
HMP378 Probe for Pressurized Pipelines
ATEX Certificate for HMT370EX and HMP370EX (Europe)
HMP378: Probe Cable 2 m, Probe 262 mm ,max +180 °C
Sensor Protection: Sintered Stainless Steel filter, all probes HM47280SP
Ball Valve ISO1/2 with Welding Joint, HMP378/8F/8H BALLVALVE-1
Transmitter without Display and Keypad
Output Units: Metric Units
Ch1: RH (0…100%)/ Ch1: T (-40…+180 °C)
Cable Lead-through: Cable Gland M20x1.5 for Cable 5…11 mm 265207SP
No Transmitter Accessories 100% Finland Origin Vaisala Vietnam HMP370EX 82T2DN
Intrinsically Safe Humidity and Temperature Probe
HMP378 Probe for Pressurized Pipelines
ATEX Certificate for HMP370EX
HMP378: Probe Cable 2 m, Probe 262 mm ,max +180 °C
Sintered Stainless Steel filter, all probes HM47280SP
Ball Valve ISO1/2 with Welding Joint, HMP378/8F/8H BALLVALVE-1
No Probe Accessories 100% Finland Origin Vaisala Vietnam
HMT370EX 0200NA1AE1NN
HMT370 Transmitter Unit only
ATEX Certificate for HMT370EX and HMP370EX (Europe)
Transmitter only, no probe
Transmitter only
Transmitter without Display and Keypad
Metric Units
Ch1: RH (0…100%)/ Ch2: T (-40…+180 °C)
Cable Gland M20x1.5 for Cable 5…11 mm 265207SP
No Probe Accessories 100% Finland Origin Vaisala Vietnam GMP251 B2B0A5C1
CO2 Probe for % Measurements
0…10% Probe with Standard Filter
4…20mA Output
Temperature Setpoint +37°C (+99°F)
Pressure Setpoint 1013 hPa
Background Gas Setpoint 0%O2, 0%RH
3 m Probe Cable with Open Wires 26719SP
Probe Mounting Clips (2 pcs) 243257SP
Single Package 100% Finland Origin Vaisala Vietnam INDIGO510 B1N1A1AAAN
INDIGO510 Transmitter without Display
Power Supply & Output: 11…35VDC / 24VAC
Cable Gland, Metal M20x1.5/6mm, 5.0 – 9.0mm
Cable Gland for One Probe
Probe Cable 1m
Mounting Plate DRW252186SP
SW Configuration Standard
Multilingual Quick Guide
Reserved 1 For Future Purposes 100% Finland Origin Vaisala Vietnam HMPX 5C1B4A0A0F0
Humidity and Temperature Probe
HMP5 probe for high temperature and flange mounting
HMP5 with 2m cable
Humicap R2 composite sensor, allows sensor purge
Sintered Stainless Steel filter HM47280SP
Start-up purge on, interval purge off, probe heat off
19200 – Use with Indigo transmitters
8, N, 2 – Use with Indigo transmitters
240 – Use with Indigo transmitters
English certificate
Mounting flange, for HMP5 210696
No connection cable 100% Finland Origin Vaisala Vietnam HMW92D
RH + T Wall mount Transmitter, ±1.7 %RH, 4…20 mA, Display 100% Finland Origin Vaisala Vietnam HMT330 5N0B021GCAF100A01CGBAA1
Premium Humidity and Temperature Transmitter with metal enclosure w/o Display
HMT335 for Flange Installations (-40..+180 °C)
HMP305 Probe with 10m Cable (+180°C, 0-10Mpa)
No Temperature Probe
Non-warmed probe, parameters RH+T+Td+a+Tw+x+h+pws available
Power Supply: Internal AC-power (110….240 VAC)
Signal Output: 4…20mA
Ch1: Tw (0…+100C)/ Ch2: T -20…+60°C (-4…+140 °F)
Metrix Unit
Cable Gland, Metal, EMC M20x1.5/6mm, 8.0 – 11.0mm, Ms/Ni/TPE/NBR, IP68
No Installation Kit
HUMICAP180 General purpose
SST Sintered Filter
Mounting Flange for 13.5mm Diameter Probe 100% Finland Origin Vaisala Vietnam INDIGO520 B2N3A1AAAN
INDIGO510 Transmitter without Display
Power Supply & Output: Universal AC-Power (100…240 VAC), EUR Cord
Metal Cable Gland for 5-9 mm Cable
Cable Gland for One Probe
Probe Cable 1m
Retrofit Mounting Plate for HMT330, DMT340, PTU300, MMT330 DRW252186SP
SW Configuration Standard
Multilingual Quick Guide
Reserved 1 For Future Purposes 100% Finland Origin Vaisala Vietnam HMPX 5D2B1A0A0F0
Humidity and Temperature Probe
HMP5 probe for high temperature and flange mounting
HMP5 with 10m cable
Humicap R2 sensor, no sensor purge
Sintered Stainless Steel filter HM47280SP
Start-up purge off, interval purge off, probe heat off
19200 – Use with Indigo transmitters
8, N, 2 – Use with Indigo transmitters
240 – Use with Indigo transmitters
English certificate
Mounting flange, for HMP5 210696
No connection cable 100% Finland Origin Vaisala Vietnam HMP60 C12A0A3A0
Humidity and Temperature Probe, ±3 %RH
Output Signal: 0 … 5 V
Ch1: RH (0…100%)/ Ch2: T -40…+60 °C
Sensor Protection: Plastic Grid with Filter DRW010525SP
Intercap sensor
Shielded Cable, 3.0m, 4-pin M8 Female Straight HMP50Z300SP
No User’s Guide
No Converter 100% Finland Origin Vaisala Vietnam HMP370EX 81T2MA1AE1NN
Intrinsically Safe Humidity and Temperature Transmitter HMT370EX
HMP378 Probe for Pressurized Pipelines
IECEx Certificate for HMT370EX and HMP370EX (Global)
HMP378: Probe Cable 2 m, Probe 262 mm ,max +180 °C
Sensor Protection: Sintered Stainless Steel filter, all probes HM47280SP
Fitting Body for Probe Mounting, NPT 1/2 Solid Structure, HMP378 212810SP
Transmitter without Display and Keypad
Output Units: Metric Units
Ch1: RH (0…100%)/ Ch1: T (-40…+180 °C)
Cable Lead-through: Cable Gland M20x1.5 for Cable 5…11 mm 265207SP
No Transmitter Accessories 100% Finland Origin Vaisala Vietnam DMT340 6Q0K1A112A1A111C2D6K0C0
Low Dew Point Transmitter
Báo tham khảo (sắp ngưng sx, hãng k khuyến cáo đặt hàng) 100% Finland Origin Vaisala Vietnam Indigo520 A1N3A1AAAN
INDIGO520 Transmitter with Display
Power Supply and output: 15…35VDC / 24VAC
No Module
Signal cable lead-through: Cable Gland, Metal M20x1.5/6mm, 5.0 – 9.0mm, 2pcs
Cable Gland for One Probe
Probe Cable 1m CBL210896-1MSP
Mounting: Retrofit Mounting Plate for HMT330, DMT340, PTU300, MMT330 DRW252186SP
Standard SW Configuration
Multilingual Quick Guide 100% Finland Origin Vaisala Vietnam DMPX 6G1C0A0A0B0
Dew Point and Temperature Probe
Probe Head and Cable: Dewpoint and Temperature Probe DMP6
DMP6 with 10m cable
DrycapS sensor
Grid filter for DMP6
Operating Pressure: 1 bar (absolute)
Baud rate 19200
Parity, Data Bit, Stop Bit: 8, N, 2
Modbus address 240
Reserved character
Probe Mountng Accessory: Cooling set for DMP6
No Connection Cable 100% Finland Origin Vaisala Vietnam PTB110 3A0AB
PTB110 Wall Mount Barometer, 0…2.5, 0…5 V, or 500…1100 Hz Output
Pressure Range 800-1100 hPa
0…5 Vdc Voltage Output
Standard Installation Kit
Pressure Fitting: Pressure Connector M5, 1/8″ barb 100% Finland Origin Vaisala Vietnam HMT330 810B101XCAX100A0ACNBAA1
Premium Humidity and Temperature Transmitter with metal enclosure
Báo tham khảo (sắp ngưng sx, hãng k khuyến cáo đặt hàng) 100% Finland Origin Vaisala Vietnam Indigo520 A1N3A1AAAN
INDIGO520 Transmitter with Display
Power Supply and Output • 15…35VDC / 24VAC
No Module
Metal Cable Glands for 5-9 mm Cables (2 pcs)
Cable Gland for One Probe
Probe Cable 1m CBL210896-1MSP
Retrofit Mounting Plate for HMT330, DMT340, PTU300, MMT330 DRW252186SP
SW Configuration: Standard
Multilingual Quick Guide
Reserved 1: None 100% Finland Origin Vaisala Vietnam HMPX 8M2B1A0A000
Humidity and Temperature Probe
Probe Head: Humidity and Temperature Probe HMP8
Cable Length: HMP8 with 10m cable
Sensor Type: Composite R2 (VHM180C)
Filter Type: SST sintered filter
Purge and Heating: Purge on, probe heat off
Baud rate 19200
Parity, Data Bit, Stop Bit: Communication settings 8, N, 2
Probe Modbus Address: Modbus address 240
Reserved character
Probe Mounting Accessory: Mounting flange
Connection Cable No connection cable
100% Finland Origin Vaisala Vietnam HM70 B0E1A0AB
Handheld Humidity and Temperature Meter, ±1 %RH
Indicator Type: Rechargeable Indicator with Euro AC Adapter
Probe with 5m cable for -70 … +180°C(-94…+356°F),w/Preheat & Purge, HMP77B
Calibration Certificate at Room Temperature
No Probe Accessories
No Connection Cable to a Transmitter
No Carrying Case
Manual Language: Multilingual Quick Guide for HM70 100% Finland Origin Vaisala Vietnam HMT330 3G0B021BCAC100A0AAABAA1
HMT333 with Remote General Purpose Probe (-40…+80/120 °C)
Báo tham khảo (sắp ngưng sx, hãng k khuyến cáo đặt hàng) 100% Finland Origin Vaisala Vietnam Indigo520 B2N3A1AAAN
INDIGO520 Transmitter without Display
Power Supply and Output: Universal AC-Power (100…240 VAC), EUR Cord
Metal Cable Glands for 5-9 mm Cables (2 pcs)
Cable Gland for One Probe
Probe Cable 1m CBL210896-1MSP
Retrofit Mounting Plate for HMT330, DMT340, PTU300, MMT330 DRW252186SP
SW Configuration: Standard
Multilingual Quick Guide
Reserved 1: None 100% Finland Origin Vaisala Vietnam HMPX 3K2A1A0A000
Humidity and Temperature Probe
Probe Head: HMP3 general purpose probe
Cable Length: HMP3 general purpose probe
Sensor Type: Humicap R2 sensor, no sensor purge
Filter Type: Plastic grid & SST net filter DRW010281SP
Start-up purge off, interval purge off, probe heat off
Parity, Data Bit, Stop Bit: Communication settings 8, N, 2
Probe Modbus Address: Modbus address 240
Reserved character
No Probe Mounting Accessory
Connection Cable No connection cable
100% Finland Origin Vaisala Vietnam Indigo300 A0A1AN1A120N0V1
Indigo300 Transmitter with Display
Probe wheel + Cable Gland Metal
Additional Lead-through M16: Plug Metal
Probe Cable 1m With probe wheel INDIGOCABLE1M
Signal Output: 4…20 mA (3.6 mA when in error state)
Metric Unit
Relative Humidity (0…100 %rh) CH1
Temperature (-40…+60 °C) CH2
No Analog Output CH3
No Mounting Accessories 100% Finland Origin Vaisala Vietnam HMP1
Wall-Mounted Humidity and Temperature Probe 100% Finland Origin Vaisala Vietnam ASM213582
Probe Holder Assembly
Probe holder assembly for HMP1 and
HMP9 probes, HMPx, TMPx, DMPx and MMPx probe bodies 100% Finland Origin Vaisala Vietnam HMP370EX 41J2GB1CC2NN
Intrinsically Safe Humidity and Temperature Transmitter HMT370EX
HMP374 Probe for Pressurized Processes
IECEx Certificate for HMT370EX and HMP370EX (Global)
HMP374: Probe Cable 5 m, max +180 °C
Sensor Protection: Sintered Stainless Steel filter, all probes HM47280SP
Fitting Body for Probe Mounting, NPT 1/2, HMP374
Transmitter with Display and Keypad, must be protected against direct sunlight to maintain EX-protection!
Output Units: Metric Units
Ch1: T (-40…+60 °C)
Ch2: T (-40…+60 °C)
Cable Gland M20x1.5 for Cable 10…14 mm 265208SP
No Transmitter Accessories 100% Finland Origin Vaisala Vietnam GMP251 A0B0C1N1
CO2 Probe for % Measurements
0…20% Probe with Standard Filter
RS-485 Modbus
Tem Compensation: Temperature Setpoint +37°C (+99°F)
Pressure Compensation: Pressure Setpoint 1013 hPa
Background Gas Setpoint 19.7%O2, 93%RH
1.5 m Probe Cable with Open Wires 223263SP
No Mounting Accessories
Single Package 100% Finland Origin Vaisala Vietnam HPP272 AB0D0N
Hydrogen Peroxide, Humidity and Temperature Probe
Ch1: H2O2 0…2000 ppm
Ch2: RS (H2O2 and H2O) 0…100%
No Special Features
Probe Cables with Open Wires (10m) 254297SP 100% Finland Origin Vaisala Vietnam DMT143 G1C1A1A5A2ASX
Miniature Dew Point Transmitter
Mechanical Connection: ISO G1/2″ Probe with DRYCAP®180D Sensor
Digital Interfaces: Digital Output RS-485
Analog Signal Output: …20 mA, 3.6 mA error state
Analog Output Scaling: -80…+20 °C Td
Alarm LED Setpoint Off, only fault indication
Process gas air
Pressure Setting for Optimized Accuracy 1 bar Absolute
Cable 10.0 m (32.8 ft) with Open Leads HMP50Z1000SP
Sensor Protection Standard sintered filter DRW010335SP
Accessories ONLY for ISO1/2″ Thread: Sampling cell with 1/4″ male connectors DMT242SC2
Standard package for DMT143
100% Finland Origin Vaisala Vietnam 242659
USB Service Cable M12-5F, RS-485 100% Finland Origin Vaisala Vietnam Repair and Calibration for DMT152 A1DBB10A100A1X
Dewpoint and Pressure Transmitter, 1…12 bar, 100% Finland Origin Vaisala Vietnam DMT152 A1DBB10A100A1X
DMT152 Transmitter for Low Dewpoint with a measurement range of -80 to -20°C
Mechanical Connection: ISO 1/2″ Thread
Measurement Parameters: Td/f, ppm
Analog Output Ch1 & Ch2 + RS-485 as Standard: 4…20 mA
Ch1: -80…+20 °C Td/f
Ch2: -80…+20 °C Td/f
Metric Units/ Pressure Not Specified No ppm Output
Sensor Protection: Mesh Filter 18um Stainless Steel
Cable for Analog Outputs and Power Supply (Port I): Shielded Cable, 2m, snap in connector
No Service Cable
Package: Cardboard Box
Quick Reference Guide DMT152 100% Finland Origin Vaisala Vietnam PTB110 1B0AA
PTB110 Wall Mount Barometer, 0…2.5, 0…5 V, or 500…1100 Hz Output
Pressure Range 500-1100 hPa
0…2.5 Vdc Voltage Output
Standard Installation Kit
Pressure Connector M5, 1/8″ barb
Pressure Connector M5, 1/8″ barb 100% Finland Origin Vaisala Vietnam HMT330 810B101XCAX100A0ACNBAA1
Premium Humidity and Temperature Transmitter with metal enclosure
Báo tham khảo (sắp ngưng sx, hãng k khuyến cáo đặt hàng) 100% Finland Origin Vaisala Vietnam HMT330 1A0B001BDAK100A0AAABAA1
Premium Humidity and Temperature Transmitter with metal enclosure
Báo tham khảo (sắp ngưng sx, hãng k khuyến cáo đặt hàng) 100% Finland Origin Vaisala Vietnam Indigo520 A1N1A1AAAN
INDIGO520 Transmitter with NO Display
Power Supply and Output • 15…35VDC / 24VAC
No Module
Metal Cable Gland for 5-9 mm Cable
Cable Gland for One Probe
Probe Cable 1m CBL210896-1MSP
Retrofit Mounting Plate for HMT330, DMT340, PTU300, MMT330 DRW252186SP
SW Configuration: Standard
Multilingual Quick Guide
Reserved 1: None 100% Finland Origin Vaisala Vietnam HMP1
Wall-Mounted Humidity and Temperature Probe 100% Finland Origin Vaisala Vietnam ASM213582
Probe Holder Assembly
Probe holder assembly for HMP1 and
HMP9 probes, HMPx, TMPx, DMPx and MMPx probe bodies 100% Finland Origin Vaisala Vietnam HMW95D
RH + T Wall mount Transmitter, ±1.7 %RH, Modbus, Display 100% Finland Origin Vaisala Vietnam HMT310 3B5A1BcK14BBDA1B2
Premium Humidity and Temperature Transmitter with metal enclosure
HMT313 for duct mounting or outdoor mounting
Non-warmed probe, parameters RH+T+Td+a+Tw+x+h+pws available
Standard Mounting Plate
Standard power supply, 10…35 VDC 24 VAC
Analog Output Signal 4…20mA
Ch1: RH 0…100%RH
Ch2: T 0…+100 °C (+32…+ 212 °F)
Metric Units
8-Pole Connector with 5m Cable 212142
User´s Guide English
HMT313 with 2 m Cable, 80 mm probe, max +80 °C
HUMICAP180RC Composite Sensor with Chemical Purge Default
Sensor Protection in Probe: Plastic Grid & Stainless Steel Netting DRW010281SP
Duct Installation Kit for Probe
Calibration Certificate At Room Temperature
HMT310 3A5A1BcK14BBDA1B2 Lựa chọn A, hiện k còn sx, buộc chọn B cho option này đối với dòng HMT313) 100% Finland Origin Vaisala Vietnam HMP110 A15B1C1B0
Humidity and Temperature Probe, ±1.5 %rh
Output: 0 … 1 V
Ch1: RH (0…100%)
Ch2: T -40…+80 °C
Sensor Protection: Plastic Grid DRW010522SP
Mouting Accessories: Pair of plastic nuts 18350SP
Humidity Sensor: Robust general purpose humidity sensor (180R)
No Probe Cable Length
User Guide: Multilingual Quick Guide HMP60 HMP110
100% Finland Origin Vaisala Vietnam HMP50Z500SP
Connection Cable, M8-4F – Open Wires, 5 m 100% Finland Origin Vaisala Vietnam DMT143 G1G1A1A3A0ASX
Miniature Dew Point Transmitter
Mechanical Connection: ISO G1/2″ Probe with DRYCAP®180D Sensor
Digital Interface: Digital Output RS-485
Analog Signal Output: 4…20 mA, 0 mA error state
Analog Output Scaling: -80…+20 °C Td
Alarm LED Setpoint: Off, only fault indication
Process gas air
Pressure Setting for Optimized Accuracy: 1 bar Absolute
Cable 3.0 m (9.8 ft) with Open Leads HMP50Z300SP
Standard sintered filter DRW010335SP
No Accessories ONLY for ISO1/2″ Thread
Standard package for DMT143
Vaisala identity
User Guide Language: Multilingual guide 100% Finland Origin Vaisala Vietnam HM70 F0D1A0AB
Handheld Humidity and Temperature Meter, ±1 %RH 100% Finland Origin Vaisala Vietnam Standard Calibration Service for HM70 F0D1A0AB
Services for HM70 (MI70-HMP77)
Humidity Calibration, 5 Points (RHCALSTD)
15 | 33 | 54 | 75 | 95
Temperature calibration at room temperature (+/-2°C from 23°C) (ROOMTEMP) 100% Finland Origin Vaisala Vietnam Standard Calibration Service for HM70 F0D1A0AB
Services for HM70 (MI70-HMP77)
Humidity Calibration, 5 Points (RHCALSTD)
15 | 33 | 54 | 75 | 95
Temperature calibration at room temperature (+/-2°C from 23°C) (ROOMTEMP) 100% Finland Origin Vaisala Vietnam Repair Service for HM70 F0D1A0AB
Repair and Calibration for Indicator (Fixed and Repair for Indicator MI70) 100% Finland Origin Vaisala Vietnam Repair Service for HM70 F0D1A0AB
Repair Service for HMP70 Probe (HMP77)
Repair and Calibration for Probe (Repair Service for HMP70 Probe) 100% Finland Origin Vaisala Vietnam HMP8
RH+T Probe for Adjustable Depth and Pressure 100% Finland Origin Vaisala Vietnam HM70 J0E1A0DB
Handheld Humidity and Temperature Meter, ±1 %RH
Rechargeable Indicator with JP AC Adapter
No Indicator Accessories
Probe with 5m cable for -70 … +180°C(-94…+356°F),w/Preheat & Purge, HMP77B
Calibration Certificate at Room Temperature
No Accessories
No Connection Cable to a Transmitter
No Cable
Weatherproof Carrying Case
Multilingual Quick Guide for HM70 100% Finland Origin Vaisala Vietnam HMP60 R00A0A1A0
Humidity and Temperature Probe, ±3 %RH
RS-485 Output
RS485 Digital Mode: All Parameters
RS-485 or Current Interface
Plastic Grid with Filter
Extra fast response humidity sensor
No Converter 100% Finland Origin Vaisala Vietnam GMP251 A0B0A0N1
CO2 Probe for % Measurements
0…20% Probe with Standard Filter
Output: RS-485 Modbus
Temperature Setpoint +37°C (+99°F)
Pressure Setpoint 1013 hPa
Background Gas Setpoint 0%O2, 0%RH 100% Finland Origin Vaisala Vietnam CBL210649SP
Flat cable, M8-4(M) – M8-4(F), 1m 100% Finland Origin Vaisala Vietnam CBL210493SP
Flat Cable, M12-5(M) – M12-5(F), 1m 100% Finland Origin Vaisala Vietnam 242659
USB Service Cable M12-5F, RS-485
Used for GMP251 100% Finland Origin Vaisala Vietnam 219690
USB Service Cable M8-4F, RS485
Used for HMP60 100% Finland Origin Vaisala Vietnam HMP60 R00A0A1A0
Humidity and Temperature Probe, ±3 %RH
RS-485 Output
RS485 Digital Mode: All Parameters
RS-485 or Current Interface
Plastic Grid with Filter
Extra fast response humidity sensor
No Converter 100% Finland Origin Vaisala Vietnam GMP251 A0B0A0N1
CO2 Probe for % Measurements
0…20% Probe with Standard Filter
Output: RS-485 Modbus
Temperature Setpoint +37°C (+99°F)
Pressure Setpoint 1013 hPa
Background Gas Setpoint 0%O2, 0%RH 100% Finland Origin Vaisala Vietnam CBL210649SP
Flat cable, M8-4(M) – M8-4(F), 1m 100% Finland Origin Vaisala Vietnam CBL210493SP
Flat Cable, M12-5(M) – M12-5(F), 1m 100% Finland Origin Vaisala Vietnam 242659
USB Service Cable M12-5F, RS-485
Used for GMP251 100% Finland Origin Vaisala Vietnam 219690
USB Service Cable M8-4F, RS485
Used for HMP60 100% Finland Origin Vaisala Vietnam HMP370EX 31G1BB1AC5AN
Intrinsically Safe Humidity and Temperature Transmitter HMT370EX
HMP373 Probe for Confined Spaces
IECEx Certificate for HMT370EX and HMP370EX (Global)
HMP373: Probe Cable 10 m, max +120 °C
Sensor Protection: Plastic grid & SST net filter, All probes DRW010281SP
Duct Installation Kit, HMP373/7 210697
Transmitter with Display and Keypad, must be protected against direct sunlight to maintain EX-protection!
Output Units: Metric Units
Ch1: RH (0…100%)
Ch2: T (-40…+60 °C)
Cable Lead-through: Cable Gland M20x1.5 for Cable 5…11 mm, 2 pcs
Mounting Plate HMT360 Mounting Compatible DRW253246SP 100% Finland Origin Vaisala Vietnam HMT370EX 100NB1AC5AN
HMT370 Transmitter Unit only
ATEX Certificate for HMT370EX and HMP370EX (Europe)
Transmitter only, no probe
Transmitter only
Transmitter with Display and Keypad, must be protected against direct sunlight to maintain EX-protection!
Metric Units
Ch1: RH (0…100%)/ Ch2: T (-40…+60 °C)
Cable Gland M20x1.5 for Cable 5…11 mm, 2 pcs
Mounting Plate HMT360 Mounting Compatible DRW253246SP 100% Finland Origin Vaisala Vietnam HMP370EX 31G1BN
Intrinsically Safe Humidity and Temperature Probe
HMP373 Probe for Confined Spaces
IECEx Certificate for HMP370EX (Global)
HMP373: Probe Cable 10 m, max +120 °C
Plastic grid & SST net filter, All probes DRW010281SP
Duct Installation Kit, HMP373/7 210697 100% Finland Origin Vaisala Vietnam HMP370EX 11A1NBJAC6AN
Intrinsically Safe Humidity and Temperature Transmitter HMT370EX
HMP371 Probe for Wall Mounting
IECEx Certificate for HMT370EX and HMP370EX (Global)
HMP371: Fixed Probe, max 60°C
Sensor Protection: Plastic grid & SST net filter, All probes DRW010281SP
No Accessories for Probe
Transmitter with Display and Keypad, must be protected against direct sunlight to maintain EX-protection!
Transmitter without Display and Keypad
Output Units: Metric (SI) -units only, for Japanese market (double check)
Ch1: RH (0…100%)/ Ch1: T (-40…+60 °C)
Cable Lead-through: Cable Gland M20x1.5 for Cable 10…14 mm, 2 pcs
Mounting Plate HMT360 Mounting Compatible DRW253246SP 100% Finland Origin Vaisala Vietnam HMP370EX 11A1NB1AC6AN
Intrinsically Safe Humidity and Temperature Transmitter HMT370EX
HMP371 Probe for Wall Mounting
IECEx Certificate for HMT370EX and HMP370EX (Global)
HMP371: Fixed Probe, max 60°C
Sensor Protection: Plastic grid & SST net filter, All probes DRW010281SP
No Accessories for Probe
Transmitter with Display and Keypad, must be protected against direct sunlight to maintain EX-protection!
Transmitter without Display and Keypad
Metric Units
Ch1: RH (0…100%)/ Ch1: T (-40…+60 °C)
Cable Lead-through: Cable Gland M20x1.5 for Cable 10…14 mm, 2 pcs
Mounting Plate HMT360 Mounting Compatible DRW253246SP 100% Finland Origin Vaisala Vietnam HPP272 AB0N0N
Hydrogen Peroxide, Humidity and Temperature Probe
Ch1: H2O2 0…2000 ppm
Ch2: RS (H2O2 and H2O) 0…100%
No Special Features
No Cable
No Additional Options 100% Finland Origin Vaisala Vietnam HPP272 AB0N0N
Hydrogen Peroxide, Humidity and Temperature Probe
Ch1: H2O2 0…2000 ppm
Ch2: RS (H2O2 and H2O) 0…100%
No Special Features
No Cable
No Additional Options 100% Finland Origin Vaisala Vietnam Services for HPP272
Product Code: HPP272SERVICES
Hydrogen Peroxide Probe Standard Calibration Service (HPP272STDCAL)
Calibration Interval (CALIBINTERVAL) 100% Finland Origin Vaisala Vietnam HMM100 23A1CL
Humidity Module for Environmental Chambers
Output Signal: 0…20 mA
Probe type: Stainless cable 3 m
Measured Parameter: RH
Humidity Sensor type: Humicap 180R for general purposes
sensor Protection: Sintered PTFE filter 219452SP
Chinese User Guide for HMM100 100% Finland Origin Vaisala Vietnam HMM100 23A1CL
Humidity Module for Environmental Chambers
Output Signal: 0…20 mA
Probe type: Stainless cable 3 m
Measured Parameter: RH
Humidity Sensor type: Humicap 180R for general purposes
sensor Protection: Sintered PTFE filter 219452SP
Chinese User Guide for HMM100 100% Finland Origin Vaisala Vietnam HPP272 AB0B0N
Hydrogen Peroxide, Humidity and Temperature Probe
4..20 mA output signals scaling for ch1 H2O2 0…2000 ppm
4..20 mA output signals scaling for ch2
RH (H2O only) 0…100%
No Special Features
Probe Cables with Open Wires (10m) 254297SP
No Additional Options
None Future2 100% Finland Origin Vaisala Vietnam INDIGO80 B0N0N1N0
Handheld Indicator
Power Supply: Euro AC-adapter, including USB-C cable
No indicator Accessories/ No Connection Cable
No Carrying case
100% Finland Origin Vaisala Vietnam GMP251 B1A0B6N1
CO2 Probe for % Measurements
Probe Type: 0…10% Probe with Standard Filter
Digital Output RS-485
Temperature Compensation Temperature Setpoint +25°C (+77°F)
Pressure Compensation Pressure Setpoint 1013 hPa
Background Gas Setpoint 21%O2, 50%RH
1.5 m Probe cable with Open Wires and 90° Plug No Mounting Accessories
100% Finland Origin Vaisala Vietnam HM70 A0D1A0AB
Probe with 5m cable for -70…+180 °C (-94…+356 °F), HMP77
Calibration Certificate at Room Temperature
No Carrying Case
Multilingual Quick Guide for HM70 100% Finland Origin Vaisala Vietnam HMT370EX 41H2FB1EE1NN
Intrinsically Safe Humidity and Temperature Transmitter HMT370EX
HMP374 Probe for Pressurized Processes
IECEx Certificate for HMT370EX and HMP370EX (Global)
HMP374: Probe Cable 2 m, max +180 °C
Sensor Protection: Sintered Stainless Steel filter, all probes
Fitting Body for Probe Mounting, M22 x 1.5, HMP374
Transmitter with Display and Keypad, must be protected against direct sunlight to maintain EX-protection!
Output Units: Metric Units
Ch1: T (-40…+180 °C)/ Ch1: T (-40…+180 °C)
Cable Lead-through: Cable Gland M20x1.5 for Cable 5…11 mm 265207SP
No Transmitter Accessories 100% Finland Origin Vaisala Vietnam INDIGO80 B0N0N1N0
Handheld Indicator
Power Supply: Euro AC-adapter, including USB-C cable
No indicator Accessories/ No Connection Cable
No Carrying case
100% Finland Origin Vaisala Vietnam HMPX 8G2D1A0A0L0
Humidity and Temperature Probe
HMP8 probe for pressures up to 40 bar
HMP8 with 2m cable
Sensor Type: Humicap R2 sensor, no sensor purge
Filter Type: Stainless Steel Grid HM47453SP
Purge and Heating: Start-up purge off, interval purge off, probe heat off
English certificate
Probe Mouting Accessories: Ball Valve ISO 1/2″ BALLVALVE-1
No connection cable 100% Finland Origin Vaisala Vietnam HMK15 A1010B12A
Humidity Calibrator
Salt chamber Two salt chambers with basic lids
LiCl Salt (11 %RH) for One Chamber
No MgCl2 Salt
NaCl Salt (75 %RH) for One Chamber
No K2SO4 Salt
Ion Exchanged Water for HMK15
Carrying Bag
No KCl Salt
No User’s Guide
100% Finland Origin Vaisala Vietnam GMP80P B0A1N00
No CO2 probe, only pump sampling system
No Calibration
Sampling pipe (stainless steel), 100 mm (3.94 in) DRW259158SP
M12-M12 1.5 m probe connection cable for Indigo80
Magnetic Hanger
100% Finland Origin Vaisala Vietnam HM70 B4A1A0DB
Handheld Humidity and Temperature Meter, ±1 %RH
Rechargeable Indicator with Euro AC Adapter
MI70 USB Connection Cable
General Purpose Probe for -20…+60 °C (-4…+140 °F), HMP75
Calibration Certificate at Room Temperature
No Probe Accessories
No Connection Cable to a Transmitter
Weatherproof Carrying Case
Manual Language: Multilingual Quick Guide for HM70 100% Finland Origin Vaisala Vietnam DMT152 A1DBB10A100A1X
Transmitter for Low Dewpoint with a measurement range of -80 to -20°C
Mechanical Connection: DMT152 Metal ISO 1/2″ Thread
Parameters: Td/f, ppm
Analog Output 4…20mA
Ch1: Dew Point -80…+20°C (-112…+68°F)T~d/f~
Ch2: Dew Point -80…+20°C (-112…+68°F)T~d/f~
Metric Units
Pressure Not Specified No ppm Output
Sensor Protection: Mesh Filter 18um Stainless Steel
Cable, Instrumentation M8/4(F)-Open, 4×0.25mm2, 2m, PVC, Snap in, BLK
No Service Cable
Cardboard Box
Quick Reference Guide DMT152 100% Finland Origin Vaisala Vietnam Repare and Service for DMT152 A1DBB10A100A1X 100% Finland Origin Vaisala Vietnam Shipping charge: 100% Finland Origin Vaisala Vietnam Code: DMT152 A1DCE11A330A1X
DMT152 Transmitter for Low Dewpoint with a measurement range of -80 to -20°C 100% Finland Origin Vaisala Vietnam HMT337SERVICES (HMT330 7S0A001BCAE200A0AACBCA1)
Humidity Calibration, 5 Points (RHCALSTD)
15 | 33 | 54 | 75 | 95
Temperature calibration at room temperature (+/-2°C from 23°C) (ROOMTEMP)
23 100% Finland Origin Vaisala Vietnam HMT337SERVICES (HMT330 7S0A001BCAE200A0AACBCA1)
Humidity Calibration, 5 Points (RHCALSTD)
15 | 33 | 54 | 75 | 95
Temperature calibration at room temperature (+/-2°C from 23°C) (ROOMTEMP)
23
Additional Analog Output Calibration, 3 points (ANALOGCAL1) 100% Finland Origin Vaisala Vietnam HMM100 83A1CL
Humidity Module for Environmental Chambers
Output Signal: 0…5 V, Clipping at 5.0 V
Probe type: Plastic PPS, 3 m cable
Measured Parameter RH
Humidity Sensor Type Humicap 180R for general purposes
Sensor Protection: Sintered PTFE filter 219452SP
Quick Reference Guide
Chinese User Guide for HMM100 100% Finland Origin Vaisala Vietnam HM70F0D1A0AB
Handheld Humidity and Temperature Meter, ±1 %RH
Rechargeable Indicator with all AC
Adapters
Probe with 5m cable for -70…+180 °C 94…+356 °F), HMP77
Calibration Certificate at Room
Temperature
Multilingual Quick Guide for HM70 100% Finland Origin Vaisala Vietnam HM70NPC
Special Calibration for New HM70 Probe
Accredited Humidity Calibration at
Room Temperature [%rh]
33 | 50 | 75 | 90 | 95
Accredited Humidity Calibration,
Additional Point [%rh]
97
Accredited Temperature Calibration at
Room Temperature (+/-2°C from 23°C)
23 100% Finland Origin Vaisala Vietnam HMT330 7S0B101BCAC100A01CABAA1
Premium Humidity and Temperature Transmitter with metal enclosure with Display Cover
Transmitter Type: HMT337 for high humidity (warmed probe option)
Probe Cable: HMP307 Probe with 2m Cable (+180°C)
No Temperature Probe
Calculations: Non-warmed probe, parameters RH+T+Td+a+Tw+x+h+pws available
Standard power supply, 10…35 VDC 24 VAC
Analog Output 4…20mA
Ch1: RH 0…100%RH
Channel 2 T (Temperature Range)
Temperature Range T -40…+80 °C (-40…+176°F)
Metric Units
No Option for Module Slot 1
Option for Module Slot 2
Cable Gland, Metal, EMC M20x1.5/6mm, 8.0 – 11.0mm, Ms/Ni/TPE/NBR, IP68
No Installation Kit for Transmitter and Probe
Humidity Sensor: HUMICAP180 General purpose
Sensor Protection: SST Sintered Filter
English User´s Guide HMT330
No PC Accessories
ISO9001 Compliant Factory Calibration. No Calibration Contract
No Maintenance Contract 100% Finland Origin Vaisala Vietnam HMPX 7E2B1A0A000
Humidity and Temperature Probe
Probe head: Humidity and Temperature Probe (HMP7)
Cable length: HMP7 with 2m cable
Sensor type: Humicap R2 (VHM180) + Pt100
SST sintered filter
Purge and heating: Start-up purge off, interval purge off, probe heat off
Baud rate: Baud rate 19200
Parity, data bit, stop bit: Communication settings (8, N, 2)
Probe Modbus address: Modbus address (240)
Reserved: Reserved character
No Probe mounting accessory
No Connection cable 100% Finland Origin Vaisala Vietnam Indigo510 A1N3A1AAAN
Indigo510 Transmitter
Transmitter for Indigo Probe with Display
Power Supply and Output: 11…35VDC / 24VAC
No Module
Signal Cable Lead-through: Cable Gland, Metal M20x1.5/6mm, 5.0 – 9.0mm, 2pcs
Cable Gland for One Probe
Probe Cable 1m
Mounting Plate
SW Configuration: Standard
Documentation: Multilingual Quick Guide 100% Finland Origin Vaisala Vietnam HM42
Handheld Humidity and Temperature Meter with HM42PROBE 100% Finland Origin Vaisala Vietnam PTB110 5A0AB
PTB110 Wall Mount Barometer, 0…2.5, 0…5 V, or 500…1100 Hz Output
Pressure Range:800-1060 hPa
0…5 Vdc Voltage Output
Standard Installation Kit
Pressure Connector M5, 1/8″ barb
English User Guide PTB110 100% Finland Origin Vaisala Vietnam INDIGO201 1A0A0
INDIGO201 Analog Output Transmitter
With Metric Units
Analog Output Settings 4…20 mA
No Probe Cable
No External Power Supply
NO Customization 100% Finland Origin Vaisala Vietnam DMPX 7E2A1A0A0D0
Dew Point and Temperature Probe
Probe Head and Cable: DMP7 for Swagelok installation
Cable length: DMP7 with 10m cable
Standard senso with Sintered SST Filter
Operating Pressure: 3 bar (absolute)
English calibration certificate
Probe mounting accessories: DMP7: Swagelok NPT 1/2″ SWG12NPT12
No Connection Cable 100% Finland Origin Vaisala Vietnam HPP272 AD0D0N
Hydrogen Peroxide, Humidity and Temperature Probe
4..20 mA output signals scaling for ch1 H2O2 0…2000 ppm
4..20 mA output signals scaling for ch2
RH (H2O only) 0…100%
No Special Features
Probe Cables with Open Wires (10m) 254297SP
No Additional Options
None Future2 100% Finland Origin Vaisala Vietnam HM70 A0D1A0AB
Handheld Humidity and Temperature Meter, ±1 %RH
Rechargeable Indicator with Euro AC Adapter
No Accessories
Probe with 5m cable for -70…+180 °C (-94…+356 °F), HMP77
Calibration Certificate at Room Temperature
No Probe Accessories
No Connection Cable to a Transmitter
No Carrying Case
Multilingual Quick Guide for HM70
100% Finland Origin Vaisala Vietnam HPP272 AD0N0N
Hydrogen Peroxide, Humidity and Temperature Probe
4..20 mA output signals scaling for ch1: H2O2 0…2000 ppm
4..20 mA output signals scaling for ch2: RH (H2O only) 0…100%
No Special Features
No Cable
No Additional Options
None Future2 100% Finland Origin Vaisala Vietnam 242659
USB Service Cable M12-5F, RS-485 100% Finland Origin Vaisala Vietnam HMT330 810B001XCAX100A01CNBAA1
Premium Humidity and Temperature Transmitter with metal enclosure 100% Finland Origin Vaisala Vietnam Standard Calibration Service for HMT338 (HMT330 810B001XCAX100A01CNBAA1)
Product Code: HMT338SERVICES
Humidity Calibration, 5 Points (RHCALSTD)
15 | 33 | 54 | 75 | 95
Temperature calibration at room temperature (+/-2°C from 23°C) (ROOMTEMP) 23 100% Finland Origin Vaisala Vietnam ANALOGCAL1
Additional Analog Output Calibration, 3 points 100% Finland Origin Vaisala Vietnam SENSORREP
Sensor Replacement Service 100% Finland Origin Vaisala Vietnam HMK15 D1110B12B
Humidity Calibrator
Salt Chamber: Three salt chambers with basic and custom lids
LiCl Salt (11 %RH) for One Chamber
MgCl2 Salt (33 %RH) for One Chamber
NaCl Salt (75 %RH) for One Chamber
No K2SO4 Salt
Ion Exchanged Water for HMK15
Carrying Bag
No KCl Salt
English User Guide for HMK15
100% Finland Origin Vaisala Vietnam 211302SP
Calibration Adapter for HMK15 100% Finland Origin Vaisala Vietnam 271550
HMK15 universal lid for Ø12, 13.5, and 18.5
mm probes 100% Finland Origin Vaisala Vietnam HMP1
Wall-Mounted Humidity and Temperature Probe 100% Finland Origin Vaisala Vietnam HMP1SERVICES
Services for HMP1
Humidity Calibration, 5 Points (RHCALSTD-C)
15 | 33 | 54 | 75 | 95
Temperature calibration at room temperature (+/-2°C from 23°C) (ROOMTEMP) 23 100% Finland Origin Vaisala Vietnam HMT330 810B121BCAL100A0AAVJAA1
HMT338 with Adjustable Insertion Depth in Pressurized Lines
HMP308 Probe (max insertion depth 371mm / 14.6 in) with 2m (6 ft) FEP Cable
No Temperature Probe
Calculation: aw+T+ppm for Specific Transformer Oil Type
Display Cover
Internal AC-power (110….240 VAC)
Signal Output: 4…20mA
Ch1: RH 0…100%RH
Ch2: T (range selected separately)
No Analog Outputs for Ch3
Analog output range for temp: T 0…+60 °C (+32…+140 °F)
Metric Units
Cable Gland, Metal, EMC M20x1.5/6mm, 8.0 – 11.0mm, Ms/Ni/TPE/NBR, IP68
No transmitter Installation Kit
HUMICAP180R General purpose and high chemical concentrations
Fitting Body ISO1/2 with No Leak Srew
Japanese User´s Guide HMT330
100% Finland Origin Vaisala Vietnam INDIGO520 A2N3A1AAAN
INDIGO520 A2N3A1AAAN
INDIGO520 Transmitter
Universal AC-Power (100…240 VAC), EUR Cord
Metal Cable Glands for 5-9 mm Cables (2 pcs)
Cable Gland for One Probe
Probe Cable 1m CBL210896-1MSP
Retrofit Mounting Plate for HMT330, DMT340, PTU300, MMT330 100% Finland Origin Vaisala Vietnam HMPX 8G2A1A0A0N0
Humidity and Temperature Probe
Probe head: HMP8 probe for pressures up to 40 bar
HMP8 with 2m cable
Humicap R2 sensor, no sensor purge
Plastic grid & SST net filter DRW010281SP
Start-up purge off, interval purge off, probe heat off
19200 – Use with Indigo transmitters
8, N, 2 – Use with Indigo transmitters
240 – Use with Indigo transmitters
English certificate
Pressure fitting ISO 1/2″, for HMP8 (DRW212076SP) 100% Finland Origin Vaisala Vietnam MMT330 7U0F101RRCB120A02EKBCA1
Moisture in Oil and Temperature Transmitter with Remote Probes
Transmitter Type: MMT337 with small probe for pressure up to 10 bar
HMP307 Probe with 10m Cable (+180°C)
No Temperature Probe
aw+T+ppm for Mineral Transformer Oil
Display Cover
Standard power supply, 10…35 VDC 24 VAC
4…20mA
Channel 1 ppm 0..500
Channel 2 ppm 0..500
Channel 3 T (Temperature Range)
T -40…+60 °C (-40…+140 °F)
Metric Units
RS-485 Interface with Galvanic Isolation (Serial ASCII, Modbus RTU)
Cable Gland, Metal, EMC M20x1.5/6mm, 8.0 – 11.0mm, Ms/Ni/TPE/NBR, IP68
No Transmitter Housing Installation
Humidity sensor with enhanced chemical resistance (180L2)
Swagelok for 12mm Probe 1/2″ NPT Thread
User´s Guide MMT330
Connection cable for MI70LINK PC Software, RS232 Serial Cable with D9 Female Connector
ISO9001 Compliant Factory Calibration. No Calibration Contract
No Maintenance Contract
100% Finland Origin Vaisala Vietnam HMT310 7B5A5CBJ15BPDA1A2
Premium Humidity and Temperature Transmitter with metal enclosure
HMT317 for high humidity (warmed probe optional)
Non-warmed probe, parameters RH+T+Td+a+Tw+x+h+pws available
Standard Mounting Plate
Standard power supply, 10…35 VDC 24 VAC
Analog Output signal: 0…10V
Ch1: T (range selected separately)
Ch2: RH 0…100%RH
Analog Output range for temperature: T 0…+60 °C (+32…+140 °F)
Metric Units
Cable Connector: 8-Pole Counter Connector
User´s Guide English
HMT317 with 2 m Cable, 80 mm probe, max 180 °C
HUMICAP180RC Composite Sensor with Chemical Purge Default
HMT313/317: Plastic Grid & Stainless Steel Netting DRW010281SP
No Temperature Probe/ No installation Kit
Calibration Certificate At Room Temperature 100% Finland Origin Vaisala Vietnam HMT330 3E0B001BCAX100B01ACBAA1
Premium Humidity and Temperature Transmitter with metal enclosure without Display
HMT333 with Remote General Purpose Probe (-40…+80/120 °C)
HMP303 Probe with 2m Cable
No Temperature Probe
Non-warmed probe, parameters RH+T+Td+a+Tw+x+h+pws available
Standard power supply, 10…35 VDC 24 VAC
Signal output: 4…20mA
Ch1: RH 0…100%RH
Ch2: T (range selected separately)
No Analog Outputs for Ch3
Analog Output Range for Temp: T Special range, please specify:
Metric Units
Cable Bushings: Conduit fitting NPT1/2
No Installation Kit
HUMICAP180 General purpose
DRW010281 PPS Grid with steel Netting
Installation Kit
100% Finland Origin Vaisala Vietnam INDIGO510 B1N2A1AAAN
INDIGO510 Transmitter without Display
Power Supply: 11…35VDC / 24VAC
Conduit Fitting, Metal M20x1.5 / 1/2″ NPT
Cable Gland for One Probe
Probe Cable 1m
Mounting Plate DRW252186SP
Multilingual Quick Guide
For Future Purposes
100% Finland Origin Vaisala Vietnam HMPX 3A2A1A0A0B0
Humidity and Temperature Probe
HMP3 general purpose probe
HMP3 with 2m cable
Humicap R2 sensor, no sensor purge
Filler Type: Plastic grid & SST net filter DRW010281SP
Start-up purge off, interval purge off, probe heat off
English certificate
Duct Installation Kit for HMP3/HMP7 100% Finland Origin Vaisala Vietnam HMT120 331A1X1BA1A0A
Humidity and Temperature Transmitter, ±1.5 %RH, 4…20 mA with Display
Humidity and Temperature, HMP113 Plastic Probe
Probe Mounted on Transmitter (Plastic Probe)
Output 4…20mA, 2-wire loop-powered
Output 1: RH 0…100%RH
Output2: Special parameter and scale (-20-60oC)
Metric Units
Sensor Protection: Plastic Grid for HMP113
No Transmitter installation
No Installation kit for probe
Cable Gland for 2…6 mm Diameter Cable
No Accessories
No Manual 100% Finland Origin Vaisala Vietnam HMP155 A4JB21B1A1A1A3A
Humidity and Temperature Probe for Outdoor Applications
HMP155A: Analog Output for Humidity and Temperature
Signal Output: 0…10V
Ch1: Air Temperature in range -80 … +60°C (-112…+140°F)
Ch2: RH (0…100%RH)
Non metric units
Senor type: General Purpose HumiCap 180R
Warmed Probe
Periodical Chemical Purge, Specific Time Intervals
Sintered PTFE-filter, Best protection for Long-term Stability 100% Finland Origin Vaisala Vietnam HMD60 A1AXA1A1A1
Humidity and Temperature Duct Transmitter
Probe Length Standard (25 cm)
4…20 mA (Loop powered)
Ch1: RH (0…100%)
Ch2: Special, please specify parameter and scale:
Sensor: Humicap R2
Stainless Steel Grid
Bushing 1 (small): Cable Gland (4…8mm)
Bushing 2 (small): Cable Gland (6…12mm)
Quick Guide, Multilingual, Loop Powered Output 100% Finland Origin Vaisala Vietnam HMW90 20BX1AA00A1
Room Humidity and Temperature Transmitter
Output: 2-wire current output
Output signal: 4…20 mA 2-wire (loop-powered)
Ch1: RH 0…100%
Ch2: T = -20-60
Display and coulor: Display Cover White RAL9003 (visible display) DRW237339SP
Metric units
Relative Humidity and Temperature
With adjustment trimmers
Multilingual Quick Guide for Analog HMW90/GMW90 Series Devices 100% Finland Origin Vaisala Vietnam HMS110 2AXVA1NN
Outdoor Humidity and Temperature Transmitter, ±2 %RH
Ch1: RH 0…100%
Ch2: T special scale, please specify:
Humidity Sensor: Robust general purpose humidity sensor (180R)
Multilingual Quick Guide for HMDW110 Series
100% Finland Origin Vaisala Vietnam HMD60 A1A1A1A0A1
Humidity and Temperature Duct Transmitter
Probe Length Standard (25 cm)
Output Signal: 4…20 mA (Loop powered)
Ch1: RH (0…100%)
Ch2: T (-20…+80°C)
Sensor: Humicap R2
Stainless Steel Grid
Bushing 1 (small): Plugged, M16x1.5
Bushing 2 (large): Cable Gland (6…12mm)
Quick Guide, Multilingual, Loop Powered Output 100% Finland Origin Vaisala Vietnam HMT120 HA0A1A21A1A0Z
Humidity and Temperature Transmitter, ±1.5 %RH, 4…20 mA
Humidity output only, HMP110 Stainless Steel Probe
Probe Mounted on Transmitter (Stainless Steel Probe)
No Display
Output 4…20mA, 2-wire loop-powered
RH 0…100%RH
Channel 2 No Output
Non Metric Units
Plastic Grid for Steel Probe
No Accessories for transmitter and probe
Cable Gland for 2…6 mm Diameter Cable
Multilingual Manual 100% Finland Origin Vaisala Vietnam HMS110 2A0VA0NN
Outdoor Humidity and Temperature Transmitter, ±2 %RH
Ch1: RH 0…100%
Ch2: Td -40…+60 °C (-40…+140 °F)
Humidity Sensor: Robust general purpose humidity sensor (180R)
100% Finland Origin Vaisala Vietnam DM70 F5B3B3B1
Handheld Dewpoint Meter for Spot-Checking Applications
Indicator Type: Rechargeable Indicator with all AC Adapters
Indicator Accesorry: MI70 USB Connection Cable
Probe Type: Probe for Dew Points -70…+30°C (-94…+86°F), DMP74B
Probe Accessory: Sampling Cell DMT242SC with Female Connectors, inlet G3/8″ & outlet G1/4″ ISO
Connection Cable to Transmitter: MI70 Connection Cable For DMT242
Weatherproof Carrying Case
Multilingual Quick Guide for DM70 100% Finland Origin Vaisala Vietnam INDIGO80 B0A1A1N0
Handheld Indicator
Power Supply: Euro AC-adapter, including USB-C cable
M12-M8 Service Cable for Indicator
M12-M12 Probe Connection Cable for probe
Weatherproof Carrying Case for Indigo80 and HMP80 and DMP80 Series Probes ASM214759
Housing colour option grey
No Other Options
100% Finland Origin Vaisala Vietnam DMP80 BG0A2AS0
Handheld Dew Point Probe
Probe with Range [-70 … +60°C Td], DRYCAP®180M sensor
Mechanical connection, ISO G1/2” thread
Sampling Cell with Female Connectors, Inlet G3/8″, Outlet G1/4″ ISO
Multilingual Quick Guide
Standard factory calibration 100% Finland Origin Vaisala Vietnam GMP251 A4B0C1N2
CO2 Probe for % Measurements
Probe Type: 0…20% Probe with Standard Filter
Output mode: 0…5V Output
Temp compensation: Temperature Setpoint +37°C (+99°F)
Pressure Setpoint 1013 hPa
Background Gas Compensations: Background Gas Setpoint 19.7%O2, 93%RH
Cable: 1.5 m Probe Cable with Open Wires 223263SP
No Mounting Accessories
10 Piece Multi-package (availalble if the order contains 10 units)
100% Finland Origin Vaisala Vietnam HMPX 7E2B1A0A000
Humidity and Temperature Probe
HMP7 probe for high humidity
HMP7 with 2m cable
Humicap R2 sensor, no sensor purge
Sintered Stainless Steel filter HM47280SP
Start-up purge off, interval purge off, probe heat off
No accessories
No connection cable
100% Finland Origin Vaisala Vietnam HMT330 5N0B001GCAF100A01CGBAA1
Premium Humidity and Temperature Transmitter with metal enclosure
HMT335 for Flange Installations (-40..+180 °C)
HMP305 Probe with 10m Cable (+180°C, 0-10Mpa)
No Temperature Probe
Non-warmed probe, parameters RH+T+Td+a+Tw+x+h+pws available
Cover without Display
Standard power supply, 10…35 VDC 24 VAC
4…20mA
Ch1 Tw (0…+100C)
Ch2: T (range selected separately)
T -20…+60°C (-4…+140 °F)
Metric Units
Cable Gland, Metal, EMC M20x1.5/6mm, 8.0 – 11.0mm, Ms/Ni/TPE/NBR, IP68
No Installation Kit
HUMICAP180 General purpose
Sensor Protection: SST Sintered Filter
Mounting Flange for 13.5mm Diameter Probe
100% Finland Origin Vaisala Vietnam INDIGO510 B1N2A1AAAN
INDIGO510 Transmitter w/o Display
Power supply and Output: 11…35VDC / 24VAC
No Module
Signal Cable Lead-through: Cable Gland, Metal M20x1.5/6mm, 5.0 – 9.0mm
Probe Cable Lead-through: Cable Gland for One Probe
Probe Cable: Probe Cable 0.2m CBL210896-03MSP
Mounting Plate DRW252186SP
SW Configuration: Standard
Documentation: Multilingual Quick Guide
Reserved 1: For Future Purposes
100% Finland Origin Vaisala Vietnam HMPX 5D2B1A0A0F0
Humidity and Temperature Probe
Probe Head: HMP5 probe for high temperature and flange mounting
Cable Length: HMP5 with 10m cable
Sensor Type: Humicap R2 sensor, no sensor purge
Filter Type: Sintered Stainless Steel filter
Purge and Heating: Purge on, probe heat off
Baud rate 19200
Parity, Data Bit, Stop Bit: Communication settings 8, N, 2
Probe Modbus Address: Modbus address 240
Reserved character
Probe Mounting Accessory: Mounting flange, for HMP5
Connection Cable No connection cable
100% Finland Origin Vaisala Vietnam HMT330 5N0B001GCAF100A01CGBAA1
Premium Humidity and Temperature Transmitter with metal enclosure
HMT335 for Flange Installations (-40..+180 °C)
HMP305 Probe with 10m Cable (+180°C, 0-10Mpa)
No Temperature Probe
Non-warmed probe, parameters RH+T+Td+a+Tw+x+h+pws available
Cover without Display
Standard power supply, 10…35 VDC 24 VAC
4…20mA
Ch1 Tw (0…+100C)
Ch2: T (range selected separately)
T -20…+60°C (-4…+140 °F)
Metric Units
Cable Gland, Metal, EMC M20x1.5/6mm, 8.0 – 11.0mm, Ms/Ni/TPE/NBR, IP68
No Installation Kit
HUMICAP180 General purpose
Sensor Protection: SST Sintered Filter
Mounting Flange for 13.5mm Diameter Probe
100% Finland Origin Vaisala Vietnam INDIGO510 B1N2A1AAAN
INDIGO510 Transmitter w/o Display
Power supply and Output: 11…35VDC / 24VAC
No Module
Signal Cable Lead-through: Cable Gland, Metal M20x1.5/6mm, 5.0 – 9.0mm
Probe Cable Lead-through: Cable Gland for One Probe
Probe Cable: Probe Cable 0.2m CBL210896-03MSP
Mounting Plate DRW252186SP
SW Configuration: Standard
Documentation: Multilingual Quick Guide
Reserved 1: For Future Purposes
100% Finland Origin Vaisala Vietnam HMPX 5D2B1A0A0F0
Humidity and Temperature Probe
Probe Head: HMP5 probe for high temperature and flange mounting
Cable Length: HMP5 with 10m cable
Sensor Type: Humicap R2 sensor, no sensor purge
Filter Type: Sintered Stainless Steel filter
Purge and Heating: Purge on, probe heat off
Baud rate 19200
Parity, Data Bit, Stop Bit: Communication settings 8, N, 2
Probe Modbus Address: Modbus address 240
Reserved character
Probe Mounting Accessory: Mounting flange, for HMP5
Connection Cable No connection cable
100% Finland Origin Vaisala Vietnam HMW90 21BT1AA00A0
Room Humidity and Temperature Transmitter
Output: 2-wire current output
Output Signal: 4…20 mA 2-wire (loop-powered)
Ch1: RH 0…100%
Ch2: T special scale, please specify:
Display Cover White RAL9003 (visible display) DRW237339SP
Metric units
Identity: With adjustment trimmers
Multilingual Quick Guide for Analog HMW90/GMW90 Series Devices 100% Finland Origin Vaisala Vietnam INDIGO201 0A0A0
INDIGO201 Analog Output Transmitter without Display
Analog Output Setting: 4…20 mA
No Probe Cable
No Power Supply
NO Customization 100% Finland Origin Vaisala Vietnam HMP1
Wall-Mounted Humidity and Temperature Probe 100% Finland Origin Vaisala Vietnam HM70 B0D1A0DB
Handheld Humidity and Temperature Meter, ±1 %RH
Rechargeable Indicator with Euro AC Adapter
No Indicator Accessories
Probe with 5m cable for -70…+180 °C (-94…+356 °F), HMP77
Calibration Certificate at Room Temperature
No Probe Accessories
Weatherproof Carrying Case
Multilingual Quick Guide for HM70 100% Finland Origin Vaisala Vietnam INDIGO80 B0A1A1N0
Handheld Indicator
Power Supply Unit: Euro AC-adapter, including USB-C cable
Connection Cables for Transmitters: M12-M8 Service Cable
Connection Cables for Probes: M12-M12 Probe Connection Cable
Weatherproof Carrying Case for Indigo80 and HMP80 and DMP80 Series Probes ASM214759
Housing colour option grey
100% Finland Origin Vaisala Vietnam HMP80 L1A1S0
Handheld Humidity Probe
Long probe (319 mm) with HUMICAP R2C Sensor
Probe connection cables: M12-M12 Probe Connection Cable
Filter: Sintered Stainless Steel Filter 100% Finland Origin Vaisala Vietnam INDIGO520 A1A1A2NAAN
INDIGO520 Transmitter with Display
Power Supply and Output: 15…35VDC / 24VAC
Module: Barometer Module 500…1100hPa Class A
Signal Cable Lead-Through: Metal Cable Gland for 5-9 mm Cable
Cable Gland for One Probe
Probe Cable 3m
Standard mounting kit
Multilingual Quick Guide 100% Finland Origin Vaisala Vietnam HMP1
Wall-Mounted Humidity and Temperature Probe 100% Finland Origin Vaisala Vietnam HMP110 V00B0C1A0
Humidity and Temperature Probe, ±1.5 %rh
Output signal: Serial Interface Mode for Vaisala Host Devices (HMT120, HMT130, HM40)
Ch1: RS485 Digital Mode: All Parameters
Ch2: RS-485 or Current Interface
Sensor Protection: Plastic Grid DRW010522SP
No Mounting Accessories
Humidity Sensor: Robust general purpose humidity sensor (180R) HUMICAP180R
Probe Cable Length
100% Finland Origin Vaisala Vietnam HMP110 V00C0C1A0
Humidity and Temperature Probe, ±1.5 %rh
Output signal: Serial Interface Mode for Vaisala Host Devices (HMT120, HMT130, HM40)
Ch1: RS485 Digital Mode: All Parameters
Ch2: RS-485 or Current Interface
Sensor Protection: Stainless Steel Sintered Filter
No Mounting Accessories
Humidity Sensor: Robust general purpose humidity sensor (180R) HUMICAP180R
Probe Cable Length 100% Finland Origin Vaisala Vietnam DMT152 D1DED11A100A1X
DMT152 Transmitter for Low Dewpoint with a measurement range of -80 to -20°C
Mechanical Connection: UNF 5/8 -18 Thread
Measurement Parameters : Td/f, ppm
Analog Output Ch1 & Ch2 + RS-485 as Standard: 4…20 mA
Analog Output Parameter or Function for Ch1: 0…500 ppm
Analog Output Parameter or Function for Ch2: 0…100 ppm
Metric Units
Ambient Pressure 1 bar(a) 14.76 psi(a)
Sensor Protection: Mesh Filter 18um Stainless Steel
Cable for Analog Outputs and Power Supply (Port I): Shielded Cable, 2m, snap in connector
No Service Cable
No Installation Accessories ONLY for ISO1/2″ Thread
No Special Labels
Cardboard Box 100% Finland Origin Vaisala Vietnam TMPX 1A1A0A0A000
Temperature Probe
Temperature Probe TMP1
Temperature Probe TMP1 with 2m cable
Temperature Sensor PT100
No Filter
Reserved character
19200 – Use with Indigo transmitters
8, N, 2 – Use with Indigo transmitters
240 – Use with Indigo transmitters
English calibration certificate
No accessories
No Connection Cable 100% Finland Origin Vaisala Vietnam GMP251 B5B0C5N1
CO2 Probe for % Measurements
Probe type: 0…10% Probe with Standard Filter
Output Mode: 0…10V Output
Temp: Temperature Setpoint +37°C (+99°F)
Pressure Setpoint 1013 hPa
Background Gas Setpoint 19.7%O2, 93%RH
3 m Probe Cable with Open Wires 26719SP
No Mounting Accessories
Single Package 100% Finland Origin Vaisala Vietnam DMT143 G1G1A1A3A0ASX
Miniature Dew Point Transmitter
Mechanical Connection: ISO G1/2″ Probe with DRYCAP®180D Sensor
Digital Output RS-485
Analog Signal output: 4…20 mA, 0 mA error state
Analog Output Scaling: -80…+20 °C Td
Alarm LED Setpoint: Off, only fault indication
Process gas air
Pressure Setting for Optimized Accuracy: 1 bar Absolute
Cable 3.0 m (9.8 ft) with Open Leads HMP50Z300SP
Sensor Protection: Standard sintered filter DRW010335SP
No Accessories ONLY for ISO1/2″ Thread
Standard package for DMT143 100% Finland Origin Vaisala Vietnam INDIGO201 1A0B0
INDIGO201 Analog Output Transmitter
Display: With Metric Units
Analog Output Settings: 4…20 mA
No probe cable
Universal mains power supply with EU/US/UK/AUS plugs
NO Customization 100% Finland Origin Vaisala Vietnam DMPX 7D2A2A0A0D0
Dew Point and Temperature Probe
Probe Head and Cable: DMP7 for Swagelok installation
DMP7 with 2m cable
Sensor type: DMP7/8: Standard sensor
Filter type: DMP5/7/8: Sintered SST Filter
Operating Pressure: 5 bar (absolute)
Baud rate 19200
Parity, Data Bit, Stop Bit: 8, N, 2
Probe Modbus Address: 240
English calibration certificate
Probe Mounting Accessory: DMP7: Swagelok NPT 1/2″ SWG12NPT12
No Connection Cable 100% Finland Origin Vaisala Vietnam HM46
Handheld Humidity and Temperature Meter with HM46PROBE 100% Finland Origin Vaisala Vietnam HM46PROBE
12 mm Stainless Steel Measurement Probe for HM40 100% Finland Origin Vaisala Vietnam HMT120 HB0AXA12A2C0Z
Humidity and Temperature Transmitter, ±1.5 %RH, 4…20 mA without display
Output Parameters: Humidity output only, HMP110 Stainless Steel Probe
Transmitter Type: 3 m Cable for Remote Probe HMT120Z300
Output 4…20mA, 2-wire loop-powered
Channel 1: custom Scaling (BUỘC CONFIRM KHI ORDER)
Channel 2 No Output
Metric Units
Sensor Protection: Plastic Grid with PTFE filter for Steel Probe DRW010525SP
No Transmitter installation
Installation Kit for Probe: Duct Installation Kit 215619
Cable Blushings: Conduit Fitting NPT 1/2″
No PC Accessories
Multilingual Manual 100% Finland Origin Vaisala Vietnam HM40INDI
Handheld Indicator 100% Finland Origin Vaisala Vietnam HMP113 V00B0C1A0
Humidity and Temperature Probe with plastic body and accuracy of ±1.5%RH
Output signal: Serial Interface Mode for Vaisala Host Devices (HMT120, HMT130, HM40)
Measured Parameter for Channel 1: RS485 Digital Mode: All Parameters
Measured Parameter for Channel 2: RS-485 or Current Interface
Sensor Protection: Plastic Grid (DRW240185SP)
No Accessories
Robust general purpose humidity sensor (180R) (HUMICAP180R)
No Cable
No User’s Guide
No Converter 100% Finland Origin Vaisala Vietnam HMT370EX 41H2FB1XE1AN
Intrinsically Safe Humidity and Temperature Transmitter HMT370EX
HMP374 Probe for Pressurized Processes
IECEx Certificate for HMT370EX and HMP370EX
Probe Cable 2 m, max +180 °C with HUMICAP® R2
Stainless Steel Sintered Filter (AISI 316L) for
General Use
Fitting Body for Probe Mounting M22 x 1.5
Transmitter with Display and Keypad
Metric Units
CH1 Analog Output Custom Scale Define
Parameter and Scale
Td (-40… 100 °C)
CH2 Analog Output Temperature -40…+180 °C (40…+356°F)
Cable Gland M20x1.5 for Cable 5…11 mm
Mounting Plate HMT360 Mounting Compatible
HMT364 D22HHK1A4BE2A3A4 is obsolete 100% Finland Origin Vaisala Vietnam 25130HM
Thermometer (red liquid) With Protecting Tube 100% Finland Origin Vaisala Vietnam HM40 A1AB
Handheld Humidity and Temperature Meter
Fixed probe HMP113 (HM41)
Alkaline Batteries (2 pcs)
Standard package
English Manual HM40 100% Finland Origin Vaisala Vietnam HM41
Handheld Humidity and Temperature Meter Standard Probe 100% Finland Origin Vaisala Vietnam INDIGO80 B1A1A1N0
Handheld Indicator
Power Supply Unit: Euro AC-adapter, including USB-C cable
Indicator Accessories: Magnetic hanger for Indigo80 handheld indicator ASM214318SP
Connection Cables for Transmitters: M12-M8 Service Cable 262195SP
Connection Cables for Probes: M12-M12 Probe Connection Cable 272075SP
Carrying case: Weatherproof Carrying Case for Indigo80 and HMP80 and DMP80 Series Probes ASM214759
Housing colour option grey
No Other Options 100% Finland Origin Vaisala Vietnam MMPX 8B1A0A0A0C0
MMP8 Moisture in Oil and Temperature Probe
Probe Head: Moisture in Oil and Temp Probe MMP8
Probe & Cable Length: MMP8 with 448mm probe and 2m cable
Sensor Type: Humicap L2 + Pt100
Filter Type: SS Grid HM47453SP
Oil Coefficients for ppm Calculations: Mineral Oil Settings
Baud Rate: 19200 – Use with Indigo transmitters
Parity, Data Bit, Stop Bit 8, N, 2 – Use with Indigo transmitters
Probe Modbus Address 240 – Use with Indigo transmitters
English calibration certificate
Probe Mounting Accessory: Pressure fitting NPT1/2 212810SP
No connection cable
